DTF-6002S | 2 head DTF Printer 60 cm
Model | DTF-6002S |
Application | Suitable for almost all types of fabric printing,t-shirts, hoodies, jeans, bags, sweatshirts, koozies, hats, golf towels, socks, masks, jackets, and sleeves etc. |
Printhead | 2pcs Epson Xp600 |
Print width | 600mm (24 inch) |
Speed | MAX 6㎡/h |
Resolution | 2400dpi |
Ink | Water-based paint ink |
Color | CMYK+W |
Ink Droplet Size | 3.5PL-12PL |
Printer size | 78*34*34cm |
Print weight | 38kg |
- Description
DTF-6002S is a compact 60 cm Direct-to-Film (DTF) printer designed for versatility and efficiency in fabric printing. Unlike its larger counterparts, the DTF-6002S offers a desktop-sized solution, making it ideal for businesses or individuals with limited space but still requiring high-quality printing capabilities. This overview will explore the DTF-6002S in detail, compare it with the DTF-6002, highlight its printhead characteristics, identify its target audience, explain the operation process, and discuss the capabilities and services offered by KAIOU.
Product Overview: DTF-6002S
The DTF-6002S is designed for small to medium-sized businesses looking for a reliable and space-saving solution for fabric printing. With 2 Epson Xp600 printheads, this model is perfect for printing on a wide range of fabrics, including:
T-shirts
Hoodies
Jeans
Bags
Sweatshirts
Hats
Golf towels
Socks
Masks
Jackets
Sleeves
KAIOU DTF-6002S vs. KAIOU DTF-6002: What Are the Differences?
The DTF-6002S and the DTF-6002 are both 60 cm DTF printers, but they cater to slightly different markets based on their size, speed, and capacity. Below are some of the key differences:
DTF-6002S (Desktop Model):
Print Speed: Up to 6㎡/h, making it suitable for smaller businesses or personal use.
Weight: 38kg, making it a lightweight, portable desktop model that can be set up in a small workspace.
Printer Size: Compact design with dimensions of 78*34*34 cm, perfect for businesses with space limitations.
Target Audience: Ideal for small print shops, startups, or home-based businesses that need flexibility and moderate production capacity.
DTF-6002 (Standard Model):
Print Speed: Up to 13㎡/h, more than double the speed of the DTF-6002S, making it ideal for higher-volume production.
Weight: 130kg, which makes it more suitable for businesses with dedicated printing spaces.
Printer Size: Larger dimensions at 18360140 cm, designed for print shops or businesses with higher production needs.
Target Audience: Mid-sized businesses, apparel factories, or large print shops that require faster output and have sufficient space.
Printhead Characteristics: Epson Xp600
Both the DTF-6002S and DTF-6002 use Epson Xp600 printheads, known for their precision, reliability, and high-quality output. The Epson Xp600 printhead offers several advantages:
Precision: The Xp600 printhead can produce fine ink droplets ranging from 3.5PL to 12PL, allowing for detailed prints with smooth gradients and vibrant colors.
Durability: These printheads are designed for long-term use, ensuring consistent performance over time, which is essential for businesses looking to maintain production quality.
Speed: While the DTF-6002S offers a slower print speed compared to the standard DTF-6002, the Xp600 printheads still deliver impressive results for small to medium production runs.
Suitable Audience
The DTF-6002S is targeted at businesses or individuals who need a flexible, compact, and cost-effective solution for fabric printing. Below are some examples of its ideal audience:
Startups and Small Businesses: Entrepreneurs looking to enter the custom apparel market will benefit from the compact size and lower investment cost of the DTF-6002S. It allows them to produce high-quality products without the need for a large workspace.
Home-Based Businesses: The DTF-6002S is perfect for home-based businesses that need a reliable printing solution without the space or budget for larger equipment. Its smaller footprint makes it easy to fit in a home office or workshop.
Small Print Shops: Print shops that offer custom apparel, promotional items, or limited edition merchandise will appreciate the versatility and reliability of the DTF-6002S. Its speed is sufficient for small batch runs or personalized orders.
Boutiques and Custom Clothing Designers: Boutiques or independent designers who need to print on-demand items will find the DTF-6002S to be an excellent choice. Its high resolution and ability to print on various fabrics make it perfect for creating unique, high-quality pieces.
Operating Process
The DTF-6002S follows a relatively straightforward process for printing designs onto fabric:
Prepare the Design: The design is first created on a computer using specialized software. This software allows for adjustments in color, resolution, and ink levels to ensure the best possible print quality.
Film Printing: The design is printed onto a DTF transfer film using the DTF-6002S printer. The printer applies CMYK colors along with a white layer that acts as a base for the design when transferred to fabric.
Powder Application: After the film is printed, adhesive powder is applied to the print. This powder ensures that the design sticks to the fabric when heat is applied.
Curing: The film, now covered with adhesive powder, is passed through a curing process to melt the powder and create a strong bond with the ink.
Transfer to Fabric: The cured film is placed on the fabric, and heat is applied using a heat press. The design is transferred from the film to the fabric during this process.
Cold Peel: Once the heat press process is complete, the film is allowed to cool before being peeled away, leaving the design on the fabric.
KAIOU's Capabilities and Services
KAIOU is known for its strong presence in the fabric printing industry, offering high-quality printers and comprehensive support services to its customers. Below are some of the ways KAIOU supports businesses using the DTF-6002S:
1. Technical Support
KAIOU provides dedicated technical support for its printers, including the DTF-6002S. This support includes on-site assistance, remote troubleshooting, and guidance on machine setup and maintenance. The technical team helps ensure that businesses can get their printers up and running quickly and that any operational issues are resolved promptly.
2. Training Programs
For customers new to DTF printing, KAIOU offers comprehensive training programs. These programs cover everything from basic machine operations to advanced printing techniques, allowing operators to maximize the potential of their DTF-6002S printer. Training can be conducted both on-site or remotely, depending on the customer’s preference.
3. Regular Software Updates
To keep up with the latest advancements in printing technology, KAIOU regularly provides software updates for its printers. These updates improve the printer’s functionality, optimize the printing process, and ensure compatibility with new materials or fabrics.
4. Parts and Consumables Supply
KAIOU offers a reliable supply chain for parts and consumables like inks, adhesive powders, and transfer films. This ensures that businesses can minimize downtime by always having access to the supplies they need.
5. Custom Solutions
KAIOU understands that every business is unique. They offer custom solutions for customers who may need specialized configurations or custom inks. KAIOU works with businesses to tailor their equipment to meet specific production needs.
KAIOU DTF-6002S is a versatile, compact, and highly efficient desktop-sized DTF printer, perfect for small businesses, startups, and home-based operations. While it offers a smaller footprint and lower production speeds compared to the DTF-6002, it still provides high-quality printing with a 2400 dpi resolution and a flexible CMYK+W color setup.
With support from KAIOU, including technical support, training, and a reliable supply of consumables, businesses can confidently invest in the DTF-6002S knowing that they are backed by a reputable brand with industry expertise.
For businesses looking to break into the fabric printing industry or expand their custom apparel offerings, the DTF-6002S offers an affordable, high-quality solution without the need for a large investment in space or equipment.
